Lawn Tractor · 1979Unverified

Allis Chalmers 914

Name: Allis Chalmers 914
Brand: Allis Chalmers

Allis Chalmers 914 — 900 Series · 14 hp. Reference specifications; pending source verification.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

14 hp

Weight

665 to 687 pounds

Hover a source tag to verify

Overview

ManufacturerAllis ChalmersReference

Garden tractorReference

Built in Port Washington, Wisconsin, USAReference

Original price was $4,999 in 1985Reference

Two-wheel driveReference

Manual steeringReference

Mechanical band brakesReference

Open operator station.Reference

Engine

14HP Kohler 512cc 1-cyl gasolineReference

Fuel tank11.4 LReference

Kohler K321Reference

gasolineReference

1-cylinderReference

air-cooled horizontal-shaftReference

Displacement31.27 ciReference

Bore/Stroke89 x 83 mmReference

Power10.4 kWReference

Air cleanerdryReference

Rated RPM3600Reference

StarterelectricReference

Starter volts12Reference

Transmission

hydrostaticReference

4-speed shuttleReference

Typebelt-driven hydrostaticReference

Gearsinfinite forward and reverseReference

Oil capacity2.8 LReference

Oil typeAllis-Chalmers Power Fluid 821Reference

Oil change400 hReference

TypeshuttleReference

Gears4 forward and reverseReference

PTO & Hydraulics

Typesleeve hitchReference

Rear PTOliveReference

Mid PTOliveReference

Front PTOliveReference

Dimensions

Wheelbase128 cmReference

Weight665 to 687 poundsReference

Front tire16-6.50x8Reference

Rear tire23-8.50x12Reference

Lawn/turf front16-6.50x8Reference

Lawn/turf rear23-8.50x12Reference

Length177 cmReference

Width93 cmReference

Height (steering wheel)100 cmReference

Height (hood)90 cmReference

Shuttle Weight301 kgReference

Hydro Weight311 kgReference

Clearance (front axle)20 cmReference

Front tread76 cmReference

Rear tread68 cmReference
