Lawn Tractor · 2009Unverified
Allis Chalmers AC130 AC23460AWS
Allis Chalmers AC130 AC23460AWS · 23 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
23 hp
Weight
280 kg
Hover a source tag to verify
Overview
ManufacturerAllis Chalmers (a part of Briggs & Stratton)Reference
Original price$2,799 (2009)Reference
Two-wheel driveReference
Steeringmanual, four-wheel steeringReference
Variants
LT2342023HP 42-inch deckReference
LT2346024HP 46-inch deckReference
AC23460AWSall-wheel steerReference
Engine
23HP Briggs & Stratton 721cc 2-cyl gasolineReference
Fuel tank13.2 LReference
Briggs & StrattonReference
gasolineReference
2-cylinderReference
air-cooledReference
Displacement44 ciReference
Power17.2 kWReference
Rated RPM3600Reference
Starter volts12Reference
Oil capacity1.9 LReference
Transmission
hydrostaticReference
TransmissionHydro GearReference
TypehydrostaticReference
Gearsinfinite forward and reverseReference
Dimensions
Weight280 kgReference
Front tire15x6.0-6Reference
Rear tire20x10.0-8Reference
Lawn/turf front15x6.0-6Reference
Lawn/turf rear20x10.0-8Reference
Length177 cmReference
Width144 cmReference
Height107 cmReference
Allis Chalmers AC23460AWS attachments
42" mid-mount mower deckReference
Electrical
GroundnegativeReference
Charging systemalternatorReference
Charging amps9Reference
Battery CCA230Reference
Battery volts12Reference
42" Mower deck
Typemid-mount Allis-ChalmersReference
Cutting width106 cmReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
