Industrial Tractor · 1959Unverified
Allis Chalmers D-10
Allis Chalmers D-10 — Industrial tractor · 39 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
39 hp
Weight
1419 kg
Hover a source tag to verify
Overview
ManufacturerAllis ChalmersReference
Industrial tractorReference
Built in West Allis, Wisconsin, USAReference
Manual steeringReference
Openoperator station.Reference
Engine
Allis Chalmers 2.4L 4-cyl gasolineReference
Fuel tank47.3 LReference
Engine (net)29.1 kWReference
Drawbar (claimed)22.8 kWReference
Allis ChalmersReference
gasolineReference
4-cylinderReference
liquid-cooledReference
Displacement2.4 LReference
Bore/Stroke89 x 98 mmReference
Power (net)29.1 kWReference
Compression7.5:1Reference
Rated RPM1650Reference
Torque185.8 NmReference
StarterelectricReference
Starter volts12Reference
Oil capacity3.8 LReference
Coolant capacity7.6 LReference
Transmission
4-speed gearReference
TypegearReference
Gears4 forward and 1 reverseReference
Clutch229mm dry discReference
Oil capacity6.2 LReference
PTO & Hydraulics
PTO (claimed)26.3 kWReference
Typeopen centerReference
Pressure103.4 barReference
Pump flow13.5 lpmReference
Rear PTO Type540Reference
Engine RPM540@1650Reference
Dimensions
Wheelbase200 cmReference
Weight1419 kgReference
Length308 cmReference
Height (hood)132 cmReference
Shipping weight1419 kgReference
Clearance (front axle)53 cmReference
Clearance (rear axle)55 cmReference
Front tread101 to 162 cmReference
Rear tread106 to 182 cmReference
Electrical
Charging systemgeneratorReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
