Tractor · 1957Unverified

Allis Chalmers D272

Name: Allis Chalmers D272
Brand: Allis Chalmers

Allis Chalmers D272 — Utility tractor · 28 hp. Reference specifications; pending source verification.

The Allis Chalmers D272 is a tractor model with a rated power output of 28 hp, positioning it in the lighter category of its class. It was manufactured from 1957 to 1960. The D272 features a 4-cylinder diesel liquid-cooled engine, paired with two-wheel drive and a 3-speed gearbox. Its listed operating weight is 934 kg, and it is suitable for operations covering up to 200 acres.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

28 hp

Weight

934 kg

Catalogue coverage

Variants represented

Richest spec table

44 rows

Recorded power

28 hp

Recorded weight

934 kg

Transmissions

3-speed sliding gear

Production years

1957-1960

Verified variants

No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.

Hover a source tag to verify

Overview

ManufacturerAllis ChalmersReference

Utility tractorReference

Built in Essendine, Lincolnshire, EnglandReference

Two-wheel driveReference

Open operator station.Reference

Engine

Allis-Chalmers 2.1L 4-cyl gasolineReference

Perkins 2.4L 3-cyl dieselReference

Fuel tank49.2 LReference

Engine20.5 kWReference

Drawbar (claimed)11.2 kWReference

Belt (claimed)14.2 kWReference

Plows1 (16-inch)Reference

Allis-ChalmersReference

gasolineReference

4-cylinderReference

liquid-cooledReference

Displacement2.1 LReference

Bore/Stroke86 x 89 mmReference

Compression5.75:1Reference

Rated RPM1650Reference

Firing order1-2-4-3Reference

Oil capacity3.8 LReference

Coolant capacity7.6 LReference

Perkins P-3Reference

dieselReference

3-cylinderReference

Displacement2.4 LReference

Bore/Stroke89 x 127 mmReference

Power20.5 kWReference

Rated RPM1900Reference

Coolant capacity5.7 LReference

Transmission

3-speed sliding gearReference

Typesliding gearReference

Gears3 forward and 1 reverseReference

PTO & Hydraulics

Rear PTOtransmissionReference

Rear PTO Type560Reference

Dimensions

Wheelbase187 cmReference

Weight934 kgReference

Front tire4.00-15Reference

Rear tire10-24Reference

Ag front4.00-15Reference

Ag rear10-24Reference

Length279 cmReference

Height160 cmReference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
