Industrial Tractor · 1960Unverified

Allis Chalmers HD-16D

Name: Allis Chalmers HD-16D
Brand: Allis Chalmers

Allis Chalmers HD-16D — Industrial Crawler tractor · 160 hp. Reference specifications; pending source verification.

The Allis Chalmers HD-16D is an industrial tractor with a rated output of 160 hp, positioning it among the higher-powered machines in its class. It was manufactured from 1960 to 1970 and features a 6-cylinder diesel liquid-cooled engine driving through a tracked undercarriage with a powershift transmission. The listed weight of this model is 15,649 kg, and it is suited to tasks covering approximately 600–1,500 acres.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

160 hp

Weight

15649 kg

Catalogue coverage

Variants represented

Richest spec table

40 rows

Recorded power

160 hp

Recorded weight

15649 kg

Transmissions

6-speed gear

Production years

1960-1970

Verified variants

No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.

Hover a source tag to verify

Overview

ManufacturerAllis ChalmersReference

Industrial Crawler tractorReference

Built in Springfield, Illinois, USAReference

DrivecrawlerReference

Open operator station.Reference

Variants

HD-16DgearReference

HD-16DCtorque converterReference

HD-16DPpower shiftReference

Engine

Allis Chalmers 13.8L 6-cyl dieselReference

Fuel tank378.5 LReference

Engine (net)119.3 kWReference

Drawbar (claimed)102.2 kWReference

Allis Chalmers 16000HReference

dieselReference

6-cylinderReference

liquid-cooledReference

Displacement13.8 LReference

Bore/Stroke133 x 165 mmReference

Power (net)119.3 kWReference

Compression14.5:1Reference

Rated RPM1600Reference

StarterelectricReference

Starter volts24Reference

Oil capacity39.7 LReference

Coolant capacity60.6 LReference

Transmission

6-speed gearReference

TypegearReference

Gears6 forward and 3 reverseReference

Dimensions

Weight15649 kgReference

20-inch tracksReference

Length463 cmReference

Width243 cmReference

Height229 cmReference

Shipping weight15649 kgReference

Ground clearance37 cmReference

Gauge187 cmReference

Allis Chalmers HD-16D Tracks

Width50 cmReference

Length on ground273 cmReference

Area on ground2.8 m²Reference

Ground pressure0.6 barReference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
