The Allis Chalmers HD-16G is an industrial tractor model with a rated output of 150 hp, positioning it among the higher-powered machines in its class. Manufactured from 1956 to 1966, it features a 6-cylinder electric liquid-cooled engine, coupled with a 3-speed gearbox and tracked undercarriage. The HD-16G has a listed weight of 22044 kg and is suited to tasks covering approximately 200–800 acres.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
150 hp
Weight
22044 kg
Catalogue coverage
Variants represented
2
Richest spec table
36 rows
Recorded power
150 hp
Recorded weight
22044 kg
Transmissions
3-speed torque converter
Production years
1956-1966
Verified variants
0
No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.
Hover a source tag to verify
Overview
ManufacturerAllis ChalmersReference
Crawler LoaderReference
Built in Springfield, Illinois, USAReference
DrivecrawlerReference
Open operator station.Reference
Engine
13.8L 6-cyl Allis ChalmersReference
Engine (net)111.9 kWReference
160000Reference
Allis ChalmersReference
6-cylinderReference
liquid-cooledReference
Displacement13.8 LReference
Bore/Stroke133 x 165 mmReference
Power (net)111.9 kWReference
Rated RPM1800Reference
StarterelectricReference
Starter volts24Reference
Oil capacity22.7 LReference
Coolant capacity68.1 LReference
Transmission
3-speed torque converterReference
Typetorque converterReference
Gears3 forward and 2 reverseReference
Capacities
Fuel378.5 LReference
PTO & Hydraulics
Hydraulic system208.2 LReference
Capacity208.2 LReference
Dimensions
Weight22044 kgReference
20-inch tracksReference
Length589 cmReference
Width281 cmReference
Height252 cmReference
Shipping weight22044 kgReference
Allis Chalmers HD-16G attachments
front-end loaderReference
Allis Chalmers HD-16G Tracks
Width50 cmReference
Length on ground294 cmReference
Area on ground2.8 m²Reference
Width55 cmReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
