Industrial Tractor · 1951Unverified
Allis Chalmers HD-9G
Allis Chalmers HD-9G — Crawler Loader · 70 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
70 hp
Weight
13335 kg
Hover a source tag to verify
Overview
ManufacturerAllis ChalmersReference
Crawler LoaderReference
Built in Springfield, Illinois, USAReference
DrivecrawlerReference
Open operator station.Reference
Engine
General Motors 4.7L 4-cyl dieselReference
Fuel tank208.2 LReference
Drawbar (claimed)52.2 kWReference
Belt (claimed)62.6 kWReference
General MotorsReference
blower dieselReference
4-cylinderReference
liquid-cooled 2-cycle vertical I-headReference
Displacement4.7 LReference
Bore/Stroke108 x 127 mmReference
Compression16.0:1Reference
Rated RPM1600Reference
Starter volts12Reference
Oil capacity15.1 LReference
Coolant capacity27.4 LReference
Transmission
6-speed gearReference
TypegearReference
Gears6 forward and 3 reverseReference
Oil capacity25.6 LReference
Dimensions
Weight13335 kgReference
16-inch tracksReference
Shipping weight13335 kgReference
Gauge187 cmReference
Allis Chalmers HD-9G attachments
front-end loaderReference
HD-9G Serial Numbers
Location:Steering clutch housing or instrument panelReference
Allis Chalmers HD-9G Tracks
Width40 cmReference
Width50 cmReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
