Tractor · 1967Unverified
Allis Chalmers HD11AG
Allis Chalmers HD11AG — Agricultural Crawler tractor · 130 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
130 hp
Weight
10432 kg
Hover a source tag to verify
Overview
ManufacturerAllis ChalmersReference
Agricultural Crawler tractorReference
DrivecrawlerReference
Open operator station.Reference
Engine
Allis-Chalmers 8.5L 6-cyl dieselReference
Fuel tank340.7 LReference
Engine (gross)96.9 kWReference
Engine (net)91.3 kWReference
Drawbar (claimed)70.8 kWReference
Allis-Chalmers 11000Reference
turbocharged dieselReference
6-cylinderReference
liquid-cooledReference
Displacement8.5 LReference
Bore/Stroke113 x 141 mmReference
Power (net)91.3 kWReference
Power (gross)96.9 kWReference
Rated RPM1800Reference
StarterelectricReference
Starter volts24Reference
Oil capacity16.1 LReference
Coolant capacity41.6 LReference
Transmission
6-speed gearReference
TypegearReference
Gears6 forward and 3 reverseReference
Dimensions
Weight10432 kgReference
16-inch tracksReference
Length378 cmReference
Width243 cmReference
Height (hood)197 cmReference
Operating weight10432 kgReference
Ground clearance35 cmReference
Gauge187 cmReference
HD11AG Serial Numbers
19671Reference
1968344Reference
1969514Reference
1970660Reference
19711044Reference
FAQ: How to read a serial number table.Reference
Allis Chalmers HD11AG Tracks
Width40 cmReference
Length on ground234 cmReference
Area on ground1.9 m²Reference
Width50 cmReference
Width55 cmReference
Width60 cmReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
