Industrial Tractor · 1959Unverified
Allis Chalmers TL-20
Allis Chalmers TL-20 — Wheel Loader · 130 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
130 hp
Weight
10546 kg
Hover a source tag to verify
Overview
ManufacturerAllis ChalmersReference
Wheel LoaderReference
Built in Deerfield, Illinois, USAReference
Drive4x4 4WDReference
Final drivesplanetaryReference
Power steeringReference
Hydraulic brakesReference
Open operator station. Cab optional with heater.Reference
Engine
Allis Chalmers 8.5L 6-cyl dieselReference
Engine (gross)96.9 kWReference
Allis Chalmers D-516Reference
dieselReference
6-cylinderReference
liquid-cooled inlineReference
Displacement8.5 LReference
Bore/Stroke113 x 141 mmReference
Power (gross)96.9 kWReference
Rated RPM2200Reference
Torque433.9 NmReference
Torque RPM1640Reference
StarterelectricReference
Starter volts24Reference
Transmission
3-speed power shiftReference
TransmissionAllisonReference
Typepower shiftReference
Gears3 forward and reverseReference
Capacities
Fuel147.6 LReference
PTO & Hydraulics
Hydraulic system127.7 LReference
Typeopen centerReference
Capacity127.7 LReference
Pressure89.6 barReference
Pump flow238.5 lpmReference
Dimensions
Wheelbase236 cmReference
Weight10546 kgReference
Front tire16.00-24Reference
Rear tire16.00-24Reference
Industrial front16.00-24Reference
Industrial rear16.00-24Reference
Length574 cmReference
Width233 cmReference
Height (steering wheel)220 cmReference
Shipping weight10546 kgReference
Ground clearance43 cmReference
Front tread187 cmReference
Rear tread187 cmReference
Allis Chalmers TL-20 attachments
front-end loaderReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
