Lawn Tractor · 1964Unverified
Amigo 1170
Amigo 1170 — Garden tractor · 8 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
8 hp
Hover a source tag to verify
Overview
ManufacturerAmigoReference
Garden tractorReference
Built in Dowagiac, Michigan, USAReference
Two-wheel driveReference
Manual steeringReference
Open operator station.Reference
Engine
8HP Kohler 1-cyl gasolineReference
Kohler K-181Reference
gasolineReference
1-cylinderReference
air-cooledReference
Power (gross)6.0 kWReference
Starter volts12Reference
Transmission
4-speedReference
TransmissionAmigo-MaticReference
Gears4 forward and 2 reverseReference
Dimensions
Wheelbase111 cmReference
Front tire4.00x8-16Reference
Rear tire6.00x12-22Reference
Lawn/turf front4.00x8-16Reference
Lawn/turf rear6.00x12-22Reference
Length157 cmReference
Height (steering wheel)93 cmReference
Height (hood)81 cmReference
Clearance (front axle)25 cmReference
Amigo 1170 attachments
36" mid-mount mower deckReference
snowblowerReference
Attachment overview
36" mid-mount mower deckReference
SnowblowerReference
36" Mower deck
Typemid-mount Amigo DC-36-5Reference
Type2-blade with manual liftReference
Cutting width91 cmReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
