Tractor · Unverified

Antonio Carraro SRX 10400

Name: Antonio Carraro SRX 10400
Brand: Antonio Carraro

Antonio Carraro SRX 10400 — Ergit 100 SeriesOrchard/Vineyard tractor · 95 hp. Reference specifications; pending source verification.

The Antonio Carraro SRX 10400 is a tractor with an approximate power output of 95 hp, a mid-range rating for its category. It is equipped with a 4-cylinder turbocharged intercooled diesel liquid-cooled engine and features four-wheel drive paired with a 16-speed gearbox. The tractor has a listed operating weight of 4718 to 5092 pounds. It is designed for use on areas of 200–800 acres.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

95 hp

Weight

4718 to 5092 pounds

Catalogue coverage

Variants represented

Richest spec table

54 rows

Recorded power

95 hp

Recorded weight

2140 kg

Transmissions

16-speed

Verified variants

No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.

Hover a source tag to verify

Overview

ManufacturerAntonio CarraroReference

Orchard/Vineyard tractorReference

Built in ItalyReference

Four-wheel driveReference

Differential lockelectro-hydraulic rearReference

Differential lockelectro-hydraulic front optionalReference

Steeringhydraulic powerReference

Hydraulic wet disc brakesReference

Two-post foldable ROPS. Optional StarLight cab with air-conditioning.Reference

Engine

VM Motori 3.0L 4-cyl dieselReference

Fuel tank50.0 LReference

Engine (gross)70.8 kWReference

VM Motori D754Reference

turbocharged intercooled dieselReference

4-cylinderReference

liquid-cooledReference

Displacement3.0 LReference

Bore/Stroke94 x 107 mmReference

EmissionsStage 3AReference

Rated Power (gross)70.8 kWReference

Fuel systemdirect injectionReference

Rated RPM2600Reference

Torque420.1 NmReference

Torque RPM1000Reference

Firing order1-3-4-2Reference

StarterelectricReference

Starter volts12Reference

Transmission

16-speedReference

Gears16 forward and reverseReference

PTO & Hydraulics

Rear TypeII/IReference

Rear lift2399 kgReference

Rear PTOindependentReference

Clutchelectro-hydraulicReference

Rear PTO Type540/540E (1.375)Reference

Front PTOindependent (optional)Reference

Front PTO Type1000Reference

Dimensions

Wheelbase134 cmReference

Weight4718 to 5092 poundsReference

Front tire9.5R20Reference

Rear tire9.5R20Reference

Standard tires (ag)Front: 9.5R20. Rear: 9.5R20Reference

Optional tires (ag)Front: 300/70R20. Rear: 300/70R20Reference

Optional tires (ag)Front: 11.2R20. Rear: 11.2R20Reference

Optional tires (ag)Front: 320/70R20. Rear: 320/70R20Reference

Optional tires (ag)Front: 320/65R18. Rear: 320/65R18Reference

Optional tires (ag)Front: 340/65R18. Rear: 320/65R18Reference

Length350 cmReference

Width105 cmReference

Height (ROPS)228 cmReference

Height (cab)213 cmReference

Weight2140 kgReference

Weight2309 kgReference

Electrical

GroundnegativeReference

Battery volts12Reference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
