Tractor · Unverified

Antonio Carraro SRX 9800

Name: Antonio Carraro SRX 9800
Brand: Antonio Carraro

Antonio Carraro SRX 9800 — Ergit 100 SeriesOrchard/Vineyard tractor · 87 hp. Reference specifications; pending source verification.

The Antonio Carraro SRX 9800 is a tractor that has a rated power output of 87 hp, a mid-range figure for its class. It is equipped with a 4-cylinder turbocharged intercooled diesel liquid-cooled engine and features a four-wheel drive configuration with a 16-speed gearbox. The tractor's operating weight is listed as being between 4850 and 5137 pounds. It is capable of operating on areas of up to 200 acres.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

87 hp

Weight

4850 to 5137 pounds

Catalogue coverage

Variants represented

Richest spec table

53 rows

Recorded power

87 hp

Recorded weight

2199 kg

Transmissions

16-speed

Verified variants

No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.

Hover a source tag to verify

Overview

ManufacturerAntonio CarraroReference

Orchard/Vineyard tractorReference

Built in ItalyReference

Four-wheel driveReference

Differential lockelectro-hydraulic rearReference

Differential lockelectro-hydraulic front optionalReference

Steeringhydraulic powerReference

Hydraulic wet disc brakesReference

Two-post foldable ROPS. Optional StarLight cab with air-conditioning.Reference

Engine

Yanmar 3.3L 4-cyl dieselReference

Fuel tank50.0 LReference

Engine (gross)64.9 kWReference

YanmarReference

turbocharged intercooled dieselReference

4-cylinder 16-valveReference

liquid-cooledReference

Displacement3.3 LReference

Bore/Stroke98 x 110 mmReference

EmissionsStage 3AReference

Rated Power (gross)64.9 kWReference

Fuel systemdirect injectionReference

Rated RPM2500Reference

Torque286.8 NmReference

Torque RPM1850Reference

StarterelectricReference

Starter volts12Reference

Transmission

16-speedReference

Gears16 forward and reverseReference

PTO & Hydraulics

Rear TypeII/IReference

Rear lift2399 kgReference

Rear PTOindependentReference

Clutchelectro-hydraulicReference

Rear PTO Type540/540E (1.375)Reference

Front PTOindependent (optional)Reference

Front PTO Type1000Reference

Dimensions

Wheelbase134 cmReference

Weight4850 to 5137 poundsReference

Front tire9.5R20Reference

Rear tire9.5R20Reference

Standard tires (ag)Front: 9.5R20. Rear: 9.5R20Reference

Optional tires (ag)Front: 300/70R20. Rear: 300/70R20Reference

Optional tires (ag)Front: 11.2R20. Rear: 11.2R20Reference

Optional tires (ag)Front: 320/70R20. Rear: 320/70R20Reference

Optional tires (ag)Front: 320/65R18. Rear: 320/65R18Reference

Optional tires (ag)Front: 340/65R18. Rear: 320/65R18Reference

Length350 cmReference

Width105 cmReference

Height (ROPS)228 cmReference

Height (cab)213 cmReference

Weight2199 kgReference

Weight2330 kgReference

Electrical

GroundnegativeReference

Battery volts12Reference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
