Tractor · Unverified

Antonio Carraro Tigrone Jona 6400

Name: Antonio Carraro Tigrone Jona 6400
Brand: Antonio Carraro

Antonio Carraro Tigrone Jona 6400 — Compact Utility tractor · 56 hp. Reference specifications; pending source verification.

The Antonio Carraro Tigrone Jona 6400 is a compact tractor with a rated output of 56 hp. It is equipped with a 3-cylinder turbocharged diesel liquid-cooled engine, which drives a four-wheel drive system via a 12-speed gearbox. The tractor weighs 1619 kg and is designed for tasks involving up to 200 acres.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

56 hp

Weight

1619 kg

Catalogue coverage

Variants represented

Richest spec table

48 rows

Recorded power

56 hp

Recorded weight

1619 kg

Transmissions

12-speed

Verified variants

No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.

Hover a source tag to verify

Overview

ManufacturerAntonio CarraroReference

Compact Utility tractorReference

Built in ItalyReference

Four-wheel driveReference

Steeringhydraulic powerReference

Mechanical wet disc brakesReference

Two-post folding ROPS.Reference

Variants

6400equal-size wheelsReference

6400Funequal size wheelsReference

Engine

VM Motori 2.1L 3-cyl dieselReference

Fuel tank40.1 LReference

Engine (gross)41.8 kWReference

VM Motori D703Reference

turbocharged dieselReference

3-cylinderReference

liquid-cooledReference

Displacement2.1 LReference

Bore/Stroke94 x 100 mmReference

EmissionsStage 3AReference

Rated Power (gross)41.8 kWReference

Fuel systemdirect injectionReference

Rated RPM2600Reference

Torque195.0 NmReference

Torque RPM1400Reference

StarterelectricReference

Starter volts12Reference

Transmission

12-speedReference

Gears12 forward and reverseReference

PTO & Hydraulics

Rear TypeIReference

Rear lift2100 kgReference

Rear PTOindependentReference

Rear PTO Type540 (1.375)Reference

Rear PTO Type540E/1000 (optional)Reference

Dimensions

Wheelbase138 cmReference

Weight1619 kgReference

Front tire7.50x16Reference

Rear tire7.50x16Reference

Ag front7.50x16Reference

Ag front8.25x16Reference

Ag front7.50x18Reference

Ag rear7.50x16Reference

Ag rear8.25x16Reference

Ag rear7.50x18Reference

Length314 cmReference

Width123 cmReference

Height (ROPS)211 cmReference

Electrical

GroundnegativeReference

Battery volts12Reference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
