Tractor · Unverified

Antonio Carraro TX 7800S

Name: Antonio Carraro TX 7800S
Brand: Antonio Carraro

Antonio Carraro TX 7800S — Utility tractor · 71 hp. Reference specifications; pending source verification.

The Antonio Carraro TX 7800S is a tractor with a rating of 71 hp, placing it at a mid-range level in its class for power output. It features a 4-cylinder diesel liquid-cooled engine, which drives through four-wheel drive via a 16-speed gearbox. The listed weight of the tractor is between 4784 and 5093 pounds. This model is suited for tasks on areas of up to 200 acres.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

71 hp

Weight

4784 to 5093 pounds

Catalogue coverage

Variants represented

Richest spec table

61 rows

Recorded power

71 hp

Transmissions

16-speed

Verified variants

No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.

Hover a source tag to verify

Overview

ManufacturerAntonio CarraroReference

Utility tractorReference

Built in ItalyReference

Four-wheel driveReference

Steeringhydraulic powerReference

Hydraulic wet disc brakesReference

Two-post ROPS. Optional EasyStar six-post canopy with optional windscreens. Optional StarLight cab with air-conditioning.Reference

Variants

TXsingle-directionReference

TRXreversibleReference

Engine

Yanmar 3.3L 4-cyl dieselReference

Fuel tank60.2 LReference

Fuel tank50.0 LReference

Engine (gross)52.9 kWReference

YanmarReference

dieselReference

4-cylinder 16-valveReference

liquid-cooledReference

Displacement3.3 LReference

Bore/Stroke98 x 110 mmReference

EmissionsStage 3AReference

Rated Power (gross)52.9 kWReference

Fuel systemdirect injectionReference

Rated RPM2500Reference

Torque236.1 NmReference

Torque RPM1600Reference

StarterelectricReference

Starter volts12Reference

Transmission

16-speedReference

Gears16 forward and reverseReference

PTO & Hydraulics

Rear TypeIReference

Rear lift2150 kgReference

Rear PTOindependentReference

Rear PTO Type540/540E (1.375)Reference

Dimensions

Wheelbase149 cmReference

Weight4784 to 5093 poundsReference

Front tire250/80-18Reference

Rear tire250/80-18Reference

Ag front250/80-18Reference

Ag front300/50/15.3Reference

Ag front320/65R18Reference

Ag front300/70R20Reference

Ag front280/70R18Reference

Ag front320/70R20Reference

Ag front400/55-17.5Reference

Ag rear250/80-18Reference

Ag rear300/50/15.3Reference

Ag rear320/65R18Reference

Ag rear300/70R20Reference

Ag rear280/70R18Reference

Ag rear320/70R20Reference

Ag rear400/55-17.5Reference

Length339 cmReference

Width137 cmReference

2170 kgReference

2219 kgReference

2310 kgReference

Electrical

GroundnegativeReference

Battery volts12Reference

Antonio Carraro TX 7800S Height

ROPS236 cmReference

ROPS212 cmReference

Cab222 cmReference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
