Lawn Tractor · 1982Unverified

Ariens HT16 934001

Name: Ariens HT16 934001
Brand: Ariens

Ariens HT16 934001 — Model year 1982-198719881989-19931994-1995 · 16 hp. Reference specifications; pending source verification.

The Ariens HT16 934001 is a lawn tractor model with an approximate power rating of 16 hp, placing it in the mid-range category for its class. It was manufactured from 1982 to 1995. This model features a 2-cylinder petrol air-cooled engine and two-wheel drive with a 4-speed gearbox. Its operating weight is listed as 248 kg, with a capacity for operating on up to 200 acres.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

16 hp

Weight

248 kg

Catalogue coverage

Variants represented

Richest spec table

44 rows

Recorded power

16 hp

Recorded weight

248 kg

Transmissions

4-speed gear

Production years

1982-1995

Verified variants

No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.

Hover a source tag to verify

Overview

ManufacturerAriensReference

Garden tractorReference

Built in Brillion, Wisconsin, USAReference

Two-wheel driveReference

SteeringmanualReference

Disc brakesReference

Open operator station.Reference

Engine

16HP Briggs & Stratton 655cc 2-cyl gasolineReference

Fuel tank17.0 LReference

Briggs & Stratton 402707Reference

gasolineReference

2-cylinderReference

air-cooled vertical-shaft horizontally-opposedReference

Displacement40 ciReference

Bore/Stroke87 x 55 mmReference

Power (gross)11.9 kWReference

StarterelectricReference

Starter volts12Reference

Oil capacity1.4 LReference

Transmission

4-speed gearReference

Typebelt-driven gearReference

Gears4 forward and 1 reverseReference

PTO & Hydraulics

Typesleeve hitchReference

Mid PTOindependentReference

Clutchmechanical pulleyReference

Dimensions

Wheelbase121 cmReference

Weight248 kgReference

Front tire15x6.00-6Reference

Rear tire23x8.50-12Reference

Lawn/turf front15x6.00-6Reference

Lawn/turf rear23x8.50-12Reference

Length170 cmReference

Width88 cmReference

Shipping weight248 kgReference

Ariens HT16 attachments

42" mid-mount mower deckReference

48" mid-mount mower deckReference

snowblowerReference

bladeReference

Electrical

GroundnegativeReference

Battery volts12Reference

Attachment overview

42" mid-mount mower deckReference

48" mid-mount mower deckReference

SnowblowerReference

BladeReference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
