Lawn Tractor · 1981Unverified
Ariens LT832 935008
Ariens LT832 935008 — Lawn tractor · 8 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
8 hp
Hover a source tag to verify
Overview
ManufacturerAriensReference
Lawn tractorReference
Built in Brillion, Wisconsin, USAReference
SteeringmanualReference
Disc brakesReference
Open operator station.Reference
Engine
8HP Tecumseh 318cc 1-cyl gasolineReference
Tecumseh TVM195Reference
gasolineReference
1-cylinderReference
air-cooled vertical-shaftReference
Displacement19.43 ciReference
Bore/Stroke79 x 64 mmReference
Power (gross)6.0 kWReference
StarterelectricReference
Starter volts12Reference
Transmission
3-speed gearReference
Typebelt-driven gearReference
Gears3 forward and 1 reverseReference
PTO & Hydraulics
Front PTOindependentReference
Clutchmechanical pulleyReference
Dimensions
Wheelbase116 cmReference
Front tire13x5.00-6Reference
Rear tire18x8.50-8Reference
Lawn/turf front13x5.00-6Reference
Lawn/turf rear18x8.50-8Reference
Length154 cmReference
Width86 cmReference
Height (steering wheel)91 cmReference
Ariens LT832 attachments
32" mid-mount mower deckReference
snowblowerReference
bladeReference
Electrical
GroundnegativeReference
Battery volts12Reference
Attachment overview
32" mid-mount mower deckReference
SnowblowerReference
BladeReference
32" Mower deck
Typemid-mount AriensReference
Type1-bladeReference
Cutting width81 cmReference
Cut height2 to 10 cmReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
