Lawn Tractor · 2000Unverified

Ariens RM1028

Ariens RM1028 — 927 Series · 10 hp. Reference specifications; pending source verification.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power
10 hp
Weight
145 kg
Hover a source tag to verify

Overview

ManufacturerAriensReference
Riding lawn mowerReference
Built in Brillion, Wisconsin, USAReference
Original price was $1,499 in 2002Reference
Two-wheel driveReference
Manual steeringReference
Mechanical band brakesReference
Open operator station.Reference

Engine

10HP Briggs & Stratton 465cc 1-cyl gasolineReference
Fuel tank2.8 LReference
Briggs & Stratton 28B707Reference
gasolineReference
1-cylinderReference
air-cooled vertical-shaftReference
Displacement28.4 ciReference
Bore/Stroke87 x 78 mmReference
Power (gross)7.5 kWReference
StarterelectricReference
Starter volts12Reference

Transmission

6-speed friction discReference
TransmissionDisc-O-MaticReference
Typefriction discReference
Gears6 forward and 1 reverseReference

PTO & Hydraulics

Mid PTOindependentReference
Clutchidler pulleyReference

Dimensions

Wheelbase115 cmReference
Weight145 kgReference
Front tire4.10-3.50x4.00Reference
Rear tire16.6x5x8.00Reference
Lawn/turf front4.10-3.50x4.00Reference
Lawn/turf rear16.6x5x8.00Reference
Length158 cmReference
Height (steering wheel)99 cmReference

Ariens RM1028 attachments

28" mid-mount mower deckReference
bladeReference

Electrical

GroundnegativeReference
Battery volts12Reference

Attachment overview

28" mid-mount mower deckReference
BladeReference

28" Mower deck

Typemid-mount AriensReference
Type1-blade with manual liftReference
Cutting width71 cmReference
Overall width88 cmReference
Cut height3 to 8 cmReference
Cut positions5Reference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
