Lawn Tractor · 1988Unverified
Ariens RM928 927033
Ariens RM928 927033 — 927 Series · 9 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
9 hp
Hover a source tag to verify
Overview
ManufacturerAriensReference
Riding lawn mowerReference
Built in Brillion, Wisconsin, USAReference
Original price was $1,600 in 1995Reference
Two-wheel driveReference
Manual steeringReference
Mechanical band brakesReference
Open operator station.Reference
Engine
9HP Kawasaki 286cc 1-cyl gasolineReference
Fuel tank2.8 LReference
Kawasaki FC290VReference
gasolineReference
1-cylinderReference
air-cooled vertical-shaftReference
Displacement17.5 ciReference
Bore/Stroke78 x 60 mmReference
Power6.7 kWReference
StarterelectricReference
Starter volts12Reference
Transmission
6-speed fiction discReference
TransmissionDisc-O-MaticReference
Typefiction discReference
Gears6 forward and 1 reverseReference
PTO & Hydraulics
Mid PTOindependentReference
Clutchidler pulleyReference
Dimensions
Wheelbase115 cmReference
Front tire4.10-3.50x4Reference
Rear tire16-6.50x8Reference
Lawn/turf front4.10-3.50x4Reference
Lawn/turf rear16-6.50x8Reference
Length158 cmReference
Height (steering wheel)99 cmReference
Ariens RM928 attachments
28" mid-mount mower deckReference
bladeReference
Electrical
GroundnegativeReference
Battery volts12Reference
Attachment overview
28" mid-mount mower deckReference
BladeReference
28" Mower deck
Typemid-mount AriensReference
Type1-blade with manual liftReference
Cutting width71 cmReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
