The Ariens YT1438 935031 is a lawn tractor with a rated power of 14 hp, a mid-range figure for its class. The model was manufactured from 1989 to 1991. It features a 1-cylinder petrol air-cooled engine, paired with a hydrostatic transmission. The tractor is suitable for operations of up to 200 acres.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
14 hp
Catalogue coverage
Variants represented
2
Richest spec table
41 rows
Recorded power
14 hp
Transmissions
hydrostatic
Production years
1989-1991
Verified variants
0
No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.
Hover a source tag to verify
Overview
ManufacturerAriensReference
Lawn tractorReference
Built in Brillion, Wisconsin, USAReference
SteeringmanualReference
Disc brakesReference
Open operator station.Reference
Engine
14HP Kohler 398cc 1-cyl gasolineReference
Kohler CV14SReference
gasolineReference
1-cylinderReference
air-cooled vertical-shaftReference
Displacement24.3 ciReference
Bore/Stroke87 x 67 mmReference
Power (gross)10.4 kWReference
StarterelectricReference
Starter volts12Reference
Transmission
hydrostaticReference
Typebelt-driven hydrostaticReference
Gearsinfinite forward and reverseReference
PTO & Hydraulics
Front PTOindependentReference
Clutchmechanical pulleyReference
Dimensions
Wheelbase116 cmReference
Front tire13x5.00-6Reference
Rear tire18x8.50-8Reference
Lawn/turf front13x5.00-6Reference
Lawn/turf rear18x8.50-8Reference
Length154 cmReference
Width86 cmReference
Height (steering wheel)91 cmReference
Ariens YT1438 attachments
38" mid-mount mower deckReference
snowblowerReference
bladeReference
Electrical
GroundnegativeReference
Battery volts12Reference
Attachment overview
38" mid-mount mower deckReference
SnowblowerReference
BladeReference
38" Mower deck
Typemid-mount AriensReference
Type2-bladeReference
Cutting width96 cmReference
Cut height2 to 10 cmReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
