Tractor · Unverified
ArmaTrac 602LP
ArmaTrac 602LP · 58 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
58 hp
Hover a source tag to verify
Overview
ManufacturerArmaTracReference
Built in Ankara, TurkeyReference
Two-wheel driveReference
Multiple wet disc brakesReference
Engine
Perkins 3.3L 3-cyl dieselReference
Fuel tank70.0 LReference
Engine43.0 kWReference
Perkins 1103C-33Reference
dieselReference
3-cylinderReference
Displacement3.3 LReference
Bore/Stroke105 x 127 mmReference
Power43.0 kWReference
Air cleanerdry with internal prefilterReference
Compression19.25:1Reference
Rated RPM2200Reference
Torque222.0 NmReference
Torque RPM1400Reference
Oil capacity7.0 LReference
Transmission
16-speedReference
Gears16 forward and 8 reverseReference
PTO & Hydraulics
Total flow38.0 lpmReference
Steering press.9.9 barReference
Rear lift2399 kgReference
Rear PTOindependentReference
Rear PTO Type540/750Reference
Dimensions
Wheelbase213 cmReference
Width176 cmReference
Height243 cmReference
Ballasted weight2669 kgReference
Ground clearance30 cmReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
