Tractor · 1950Unverified

ATC GT-25 Terratrac

Name: ATC GT-25 Terratrac
Brand: ATC

ATC GT-25 Terratrac — Agricultural Crawler tractor · 25 hp. Reference specifications; pending source verification.

The ATC GT-25 Terratrac is a tractor model with a rating of approximately 25 horsepower, positioning it at the lower end of its class in terms of power output. It was manufactured from 1950 to 1953. The GT-25 Terratrac features a 4-cylinder, petrol, liquid-cooled engine paired with a tracked undercarriage and a 3-speed gearbox. Its listed operating weight is 1492 kg, and it is suitable for operations covering up to 200 acres.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

25 hp

Weight

1492 kg

Catalogue coverage

Variants represented

Richest spec table

51 rows

Recorded power

25 hp

Recorded weight

1492 kg

Transmissions

3-speed gear

Production years

1950-1953

Verified variants

No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.

Hover a source tag to verify

Overview

ManufacturerATCReference

Agricultural Crawler tractorReference

Built in Churubusco, Indiana, USAReference

DrivecrawlerReference

Open operator station.Reference

Engine

Continental 2.0L 4-cyl gasolineReference

Fuel tank37.9 LReference

Engine18.6 kWReference

Belt (claimed)18.6 kWReference

Plows2 (14-inch)Reference

Continental F-124Reference

gasolineReference

4-cylinderReference

liquid-cooledReference

Displacement2.0 LReference

Bore/Stroke76 x 111 mmReference

Power18.6 kWReference

Fuel systemcarburetorReference

Air cleaneroil bathReference

Rated RPM2000Reference

StartermanualReference

StarterelectricReference

Starter volts6Reference

Coolant capacity10.4 LReference

Transmission

3-speed gearReference

TypegearReference

Gears3 forward and 1 reverseReference

Oil capacity7.6 LReference

PTO & Hydraulics

Rear PTO Type540 (1.375)Reference

Engine RPM540@1662Reference

Dimensions

Weight1492 kgReference

7.5-inch tracksReference

Length243 cmReference

Width111 cmReference

Height (hood)129 cmReference

Operating weight1492 kgReference

Ground clearance43 cmReference

Gauge91/106/121/142/152/182 cmReference

GT-25 Serial Numbers

19505500Reference

19515831Reference

19526673Reference

19536794Reference

Final6822Reference

FAQ: How to read a serial number table.Reference

Capacities

Diameter21 cmReference

Width16 cmReference

RPM1220Reference

ATC GT-25 Tracks

Width19 cmReference

Length on ground129 cmReference

Area on ground0.5 m²Reference

Ground pressure0.3 barReference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
