Tractor · 1954Unverified
ATC Terratrac 200
ATC Terratrac 200 — Model year 1954-19551955-1956 · 37 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
37 hp
Weight
2204 kg
Hover a source tag to verify
Overview
ManufacturerATCReference
Agricultural Crawler tractorReference
Built in Churubusco, Indiana, USAReference
DrivecrawlerReference
Final drivesspur gearReference
Contracting band brakesReference
Open operator station.Reference
Engine
Continental 2.3L 4-cyl gasolineReference
Fuel tank37.9 LReference
Engine (gross)27.2 kWReference
Drawbar (claimed)19.2 kWReference
Plows3Reference
Continental F-140Reference
gasolineReference
4-cylinderReference
liquid-cooledReference
Displacement2.3 LReference
Bore/Stroke81 x 111 mmReference
Power (gross)27.2 kWReference
Fuel systemcarburetorReference
Air cleaneroil bathReference
Rated RPM1850Reference
StarterelectricReference
Starter volts6Reference
Coolant capacity11.4 LReference
Transmission
3-speed gearReference
TypegearReference
Gears3 forward and 1 reverseReference
Clutchdry discReference
Oil capacity2.8 LReference
Oil capacity4.7 LReference
PTO & Hydraulics
Rear PTOtransmissionReference
Rear PTO Type540 (1.375)Reference
Engine RPM540@1622Reference
Dimensions
Weight2204 kgReference
10-inch tracksReference
Length243 cmReference
Width132 cmReference
Height (hood)129 cmReference
Ground clearance40 cmReference
Gauge106/121/142/152/167/182 cmReference
ATC 200 attachments
bladeReference
200 Serial Numbers
1954200-001Reference
1955200-002Reference
Final200-080Reference
FAQ: How to read a serial number table.Reference
Capacities
Diameter15 cmReference
Width17 cmReference
RPM664Reference
Speed317.91 meters/minReference
ATC 200 Tracks
Width25 cmReference
Length on ground137 cmReference
Area on ground0.7 m²Reference
Ground pressure0.3 barReference
Width30 cmReference
Area on ground0.8 m²Reference
Ground pressure0.2 barReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
