Tractor · 1954Unverified
ATC Terratrac 300
ATC Terratrac 300 — Agricultural Crawler tractor · 37 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
37 hp
Weight
4830 to 7160 pounds
Hover a source tag to verify
Overview
ManufacturerATCReference
Agricultural Crawler tractorReference
Built in Churubusco, Indiana, USAReference
DrivecrawlerReference
Final drivesspur gearReference
Contracting band brakesReference
Open operator station.Reference
Engine
Continental 2.3L 4-cyl gasolineReference
Engine (gross)27.2 kWReference
Plows3Reference
Continental F-140Reference
gasolineReference
4-cylinderReference
liquid-cooledReference
Displacement2.3 LReference
Bore/Stroke81 x 111 mmReference
Power (gross)27.2 kWReference
Rated RPM1850Reference
Torque144.4 NmReference
Starter typeelectricReference
Transmission
3-speed gearReference
TypegearReference
Gears3 forward and 1 reverseReference
Clutchdry discReference
PTO & Hydraulics
Typeopen centerReference
Pump flow41.6 lpmReference
Dimensions
Weight4830 to 7160 poundsReference
11-inch tracksReference
Length233 cmReference
Height161 cmReference
Ground clearance40 cmReference
2190 kgReference
2472 kgReference
3247 kgReference
ATC 300 attachments
bladeReference
front-end loaderReference
300 Serial Numbers
1954300-001Reference
1955300-027Reference
Final300-161Reference
FAQ: How to read a serial number table.Reference
Capacities
Diameter15 cmReference
Width17 cmReference
RPM664Reference
Speed317.91 meters/minReference
Attachment overview
BladeReference
Front-end loaderReference
ATC 300 Tracks
Width27 cmReference
Length on ground137 cmReference
Area on ground0.8 m²Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
