Tractor · 1954Unverified
ATC Terratrac 400
ATC Terratrac 400 — Model year 1954-19551955-1956 · 43 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
43 hp
Weight
5125 to 8190 pounds
Hover a source tag to verify
Overview
ManufacturerATCReference
Agricultural Crawler tractorReference
Built in Churubusco, Indiana, USAReference
DrivecrawlerReference
Final drivesspur gearReference
Open operator station.Reference
Engine
Continental 2.7L 4-cyl gasolineReference
Continental 2.6L 4-cyl dieselReference
Engine (gross)31.7 kWReference
Continental F-162Reference
gasolineReference
4-cylinderReference
liquid-cooledReference
Displacement2.7 LReference
Bore/Stroke87 x 111 mmReference
Power (gross)31.7 kWReference
Rated RPM1850Reference
Torque168.6 NmReference
StarterelectricReference
Starter volts6Reference
Continental GD-157Reference
dieselReference
Displacement2.6 LReference
Bore/Stroke86 x 111 mmReference
Power (gross)28.3 kWReference
Torque149.2 NmReference
Starter volts12Reference
Transmission
3-speed gearReference
TypegearReference
Gears3 forward and 1 reverseReference
Clutchdry discReference
PTO & Hydraulics
Typeopen centerReference
Pump flow41.6 lpmReference
Dimensions
Weight5125 to 8190 poundsReference
12-inch tracksReference
Length256 cmReference
Height161 cmReference
Ground clearance40 cmReference
2324 kgReference
2633 kgReference
3714 kgReference
ATC 400 attachments
bladeReference
front-end loaderReference
400 Serial Numbers
1954400-001 (gas)Reference
1955400-031 (gas)Reference
Final400-122 (gas)Reference
1955D400-001 (diesel)Reference
FinalD400-122 (diesel)Reference
FAQ: How to read a serial number table.Reference
Attachment overview
BladeReference
Front-end loaderReference
ATC 400 Tracks
Width30 cmReference
Length on ground144 cmReference
Area on ground0.9 m²Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
