Tractor · 1955Unverified
ATC Terratrac 600
ATC Terratrac 600 — Agricultural Crawler tractor · 62 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
62 hp
Weight
7170 to 12893 pounds
Hover a source tag to verify
Overview
ManufacturerATCReference
Agricultural Crawler tractorReference
Built in Churubusco, Indiana, USAReference
Total built1,007Reference
DrivecrawlerReference
Hydraulic shoe brakesReference
Open operator station.Reference
Engine
Continental 3.4L 6-cyl gasolineReference
Continental 3.4L 4-cyl dieselReference
Fuel tank94.6 LReference
Engine (gross)46.2 kWReference
Engine (net)41.8 kWReference
Continental F-209Reference
gasolineReference
6-cylinderReference
liquid-cooledReference
Displacement3.4 LReference
Bore/Stroke81 x 111 mmReference
Power (net)41.8 kWReference
Power (gross)46.2 kWReference
Rated RPM2250Reference
Torque222.4 NmReference
Torque RPM1200Reference
StarterelectricReference
Starter volts6Reference
Oil capacity4.7 LReference
Coolant capacity15.1 LReference
Continental ED-208Reference
dieselReference
4-cylinderReference
Displacement3.4 LReference
Bore/Stroke94 x 124 mmReference
Torque210.2 NmReference
Torque RPM1400Reference
Starter volts12Reference
Oil capacity6.6 LReference
Transmission
4-speed power-shift torque converterReference
Typepower-shift torque converterReference
Gears4 forward and reverseReference
ClutchhydraulicReference
Oil capacity22.7 LReference
PTO & Hydraulics
Typeopen centerReference
Pressure86.2 barReference
Pump flow71.9 lpmReference
Pump flow113.6 lpmReference
Dimensions
Wheelbase159 cmReference
Weight7170 to 12893 poundsReference
14-inch tracksReference
Length287 cmReference
Height (exhaust)172 cmReference
Ground clearance39 cmReference
Gauge123 cmReference
Tractor3252 kgReference
Dozer4336 kgReference
Backhoe-loader5848 kgReference
ATC 600 attachments
bladeReference
front-end loaderReference
backhoeReference
600 Serial Numbers
1955656-001 (gas)Reference
1956656-117 (gas)Reference
1957656-479 (gas)Reference
1955D656-001 (diesel)Reference
1956D656-025 (diesel)Reference
1957D656-418 (diesel)Reference
FAQ: How to read a serial number table.Reference
Attachment overview
BladeReference
Front-end loaderReference
BackhoeReference
Case Backhoe
Backhoe typeCase BackhoeReference
Bucket width48 cmReference
Bucket width60 cmReference
Digging depth381 cmReference
Reach from pivot492 cmReference
Loading height452 cmReference
Swing Arc180°Reference
ATC 600 Tracks
Width35 cmReference
Length on ground159 cmReference
Area on ground1.1 m²Reference
Width40 cmReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
