Tractor · 2021Unverified

Bad Boy 2024

Name: Bad Boy 2024
Brand: Bad Boy

Bad Boy 2024 — 20 Series · 24 hp. Reference specifications; pending source verification.

The Bad Boy 2024 is a compact tractor, featuring a 24 hp rating, making it a suitable option for smaller-scale operations. It was produced between 2021 and 2023 and is equipped with a 3-cylinder diesel liquid-cooled engine, which powers four-wheel drive via a hydrostatic transmission. The tractor weighs 829 kg, and is suitable for tasks covering areas of approximately up to 200 acres.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

24 hp

Weight

829 kg

Catalogue coverage

Variants represented

Richest spec table

70 rows

Recorded power

24 hp

Recorded weight

829 kg

Transmissions

hydrostatic

Production years

2021-2023

Verified variants

No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.

Hover a source tag to verify

Overview

DistributorBad BoyReference

ManufacturerTYMReference

Sub-Compact Utility tractorReference

Four-wheel driveReference

Differential lockmechanical rearReference

Power steeringReference

Wet disc brakesReference

Two-post folding ROPS.Reference

Engine

TYM 1.2L 3-cyl dieselReference

Fuel tank23.1 LReference

Engine (gross)17.9 kWReference

TYM A1100N2Reference

dieselReference

3-cylinderReference

liquid-cooled inlineReference

Displacement1.2 LReference

Bore/Stroke78 x 82 mmReference

Power (gross)17.9 kWReference

Fuel systemindirect injectionReference

Air cleanerdryReference

Compression21.5:1Reference

Rated RPM2600Reference

StarterelectricReference

Starter volts12Reference

Transmission

hydrostaticReference

TypehydrostaticReference

Gearsinfinite forward and reverse (2-range)Reference

PTO & Hydraulics

PTO (claimed)13.4 kWReference

Typeopen centerReference

Pump flow16.3 lpmReference

Total flow28.0 lpmReference

Steering flow11.7 lpmReference

Rear TypeIReference

Controlposition controlReference

Rear lift (at ends)650 kgReference

Rear lift (at 24"/610mm)294 kgReference

Rear PTOindependentReference

Rear PTO Type540 (1.375)Reference

Engine RPM540@2600Reference

Engine RPM960@2600Reference

Mid PTOindependentReference

Engine RPM2500@2600Reference

Dimensions

Wheelbase150 cmReference

Weight829 kgReference

Weight375 kgReference

Industrial front23x8.5-12Reference

Industrial rear12-16.5Reference

Length271 cmReference

Width112 cmReference

Height (ROPS)221 cmReference

Ground clearance32 cmReference

Front tread85 cmReference

Rear tread87 cmReference

Bad Boy 2024 attachments

front-end loaderReference

backhoeReference

2024 Serial Numbers

Location:Serial number decal on the right side of the tractor frame, above the front axle.Reference

Electrical

GroundnegativeReference

Charging systemalternatorReference

Battery volts12Reference

Attachment overview

Front-end loaderReference

BackhoeReference

Bad Boy BBH200 Backhoe

Backhoe typeBad Boy BBH200 BackhoeReference

Transport height179 cmReference

Bucket width30 cmReference

2-Foot flat digging depth193 cmReference

Reach from pivot264 cmReference

Loading height162 cmReference

Bucket Rotation180°Reference

Swing Arc150°Reference

Bucket force929 kgReference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
