Tractor · 1995Unverified
Belarus 1005
Belarus 1005 — Row-Crop tractor · 92 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
92 hp
Weight
4025 kg
Hover a source tag to verify
Overview
ManufacturerBelarusReference
Row-Crop tractorReference
Built in Minsk, BelarusReference
Two-wheel driveReference
Final drivesspur gearReference
Differential lockhydraulicReference
Power steeringReference
Mechanical disc brakesReference
Cab standard.Reference
Variants
10052WDReference
10254WDReference
Engine
Belarus 4.7L 4-cyl dieselReference
Engine74.6 kWReference
BelarusReference
turbocharged dieselReference
4-cylinderReference
liquid-cooledReference
Displacement4.7 LReference
Bore/Stroke110 x 125 mmReference
Power74.6 kWReference
Fuel systemdirect injectionReference
Air cleaneroil bathReference
Compression16:1Reference
Rated RPM1800Reference
StarterelectricReference
Starter volts24Reference
Oil capacity15.0 LReference
Coolant capacity20.0 LReference
Transmission
18-speedReference
Gears18 forward and 4 reverseReference
Clutchdry discReference
Oil capacity39.9 LReference
PTO & Hydraulics
PTO (claimed)68.6 kWReference
Hydraulic system20.4 LReference
Typeopen centerReference
Capacity20.4 LReference
Pressure155.1 barReference
Valves2 or 3Reference
Pump flow45.0 lpmReference
Rear TypeIIReference
Controlposition and draft controlReference
Rear lift (at ends)1980 kgReference
Rear PTOindependentReference
Rear PTO Type540/1000 (1.375)Reference
Engine RPM540@1632Reference
Engine RPM1000@1673Reference
Capacities
Fuel129.8 LReference
Dimensions
Wheelbase249 cmReference
Weight4025 kgReference
Front tire9.50x20Reference
Rear tire16.9x38Reference
Standard tires (ag)Front: 9.50x20. Rear: 16.9x38Reference
Length414 cmReference
Width198 cmReference
Height287 cmReference
Shipping weight4025 kgReference
Clearance (front axle)64 cmReference
Clearance (rear axle)46 cmReference
Front tread145 to 184 cmReference
Rear tread146 to 210 cmReference
Electrical
Charging systemalternatorReference
Charging amps50Reference
Battery volts12Reference
Speeds
With 16.9-38 rear tires.Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
