Tractor · 1997Unverified
Belarus 3011
Belarus 3011 — Utility tractor · 29 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
29 hp
Weight
2007 kg
Hover a source tag to verify
Overview
ManufacturerBelarusReference
Utility tractorReference
Built in Minsk, BelarusReference
Original price was $9,400 in 1999Reference
Two-wheel driveReference
Final drivesspur gearReference
Differential lockmechanical rearReference
Manual steeringReference
Mechanical disc brakesReference
Open operator station. ROPS and cab available.Reference
Variants
30118-speed 2WDReference
30216-speed 2WDReference
30456-speed 4WDReference
T-30AEuropean model designationReference
Engine
MTZ 2.1L 2-cyl dieselReference
Engine26.8 kWReference
MTZ D-120Reference
dieselReference
2-cylinderReference
air-cooledReference
Displacement2.1 LReference
Bore/Stroke105 x 120 mmReference
Power26.8 kWReference
Air cleaneroil bathReference
Compression16.5:1Reference
Rated RPM2000Reference
StarterelectricReference
Starter volts12Reference
Oil capacity7.0 LReference
Transmission
8-speed gearReference
TypegearReference
Gears8 forward and 6 reverseReference
Clutchdry discReference
Oil capacity9.9 LReference
Transmission operated with clutch and two levers. The mode selection lever chooses between forward, reverse, or netural. The range selection lever chooses one of eight gears, although SL1 and SL2 are forward only.Reference
PTO & Hydraulics
PTO (claimed)21.3 kWReference
Hydraulic system9.8 LReference
Capacity9.8 LReference
Pressure171.3 barReference
Valves1Reference
Pump flow15.9 lpmReference
Rear TypeIIReference
Rear lift (at ends)997 kgReference
Rear PTOtransmissionReference
Rear PTO Type540 (1.375)Reference
Engine RPM540@1775Reference
Capacities
Fuel53.0 LReference
Dimensions
Wheelbase177 cmReference
Weight2007 kgReference
Front tire6.00-16Reference
Rear tire11.2-28Reference
Standard tires (ag)Front: 6.00-16. Rear: 11.2-28Reference
Length317 cmReference
Width167 cmReference
Height (ROPS)255 cmReference
Shipping weight2007 kgReference
Clearance (drawbar)31 cmReference
Front tread119 to 139 cmReference
Rear tread119 to 147 cmReference
Speeds
With 11.2-28 rear tires.Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
