Tractor · 1994Unverified
Belarus 405A
Belarus 405A — 400A Series · 51 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
51 hp
Weight
3470 kg
Hover a source tag to verify
Overview
ManufacturerBelarusReference
Utility tractorReference
Built in Minsk, BelarusReference
Original price was $15,000 in 1997Reference
Two-wheel driveReference
Final drivesspur gearReference
Differential lockmechanical rearReference
Power steeringReference
Mechanical band brakesReference
Cab standard.Reference
Variants
400A2WD ROPSReference
405A2WD CabReference
420A4WD ROPSReference
425A4WD CabReference
Engine
Belarus 4.1L 4-cyl dieselReference
Engine42.5 kWReference
BelarusReference
dieselReference
4-cylinderReference
air-cooledReference
Displacement4.1 LReference
Bore/Stroke105 x 120 mmReference
Power42.5 kWReference
Air cleaneroil bathReference
Compression16.5:1Reference
Rated RPM1800Reference
Torque219.7 NmReference
Torque RPM1350Reference
Firing order1-3-4-2Reference
Transmission
8-speedReference
Transmissionsliding gearReference
Gears8 forward and 6 reverseReference
PTO & Hydraulics
PTO (claimed)38.0 kWReference
Hydraulic system15.5 LReference
Typeopen centerReference
Capacity15.5 LReference
Pressure141.3 barReference
Valves2Reference
Pump flow45.0 lpmReference
Rear TypeIIReference
Controlposition and draft controlReference
Rear lift (at ends)1356 kgReference
Rear PTOindependentReference
Rear PTO Type540 (1.375)Reference
Engine RPM540@1620Reference
Capacities
Fuel73.8 LReference
Dimensions
Wheelbase214 cmReference
Weight3470 kgReference
Front tire6.5-16Reference
Rear tire13.6-38Reference
Ag front6.5-16Reference
Ag rear13.6-38Reference
405A Serial Numbers
Location:Serial number plate on the rear of the tractor, on the toolbox.Reference
Electrical
Charging systemalternatorReference
Charging amps50Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
