Tractor · 1983Unverified
Belarus 505
Belarus 505 — Progress Series · 59 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
59 hp
Weight
3619 kg
Hover a source tag to verify
Overview
ManufacturerBelarusReference
Built in Minsk, BelarusReference
Two-wheel driveReference
Power steeringReference
Mechanical disc brakesReference
Variants
5254WDReference
Engine
MTZ 4.8L 4-cyl dieselReference
Engine48.5 kWReference
MTZ D-60Reference
dieselReference
4-cylinderReference
liquid-cooledReference
Displacement4.8 LReference
Bore/Stroke110 x 125 mmReference
Power48.5 kWReference
Air cleaneroil bathReference
Compression16:1Reference
Rated RPM1800Reference
Torque267.1 NmReference
Torque RPM1300Reference
Firing order1-3-4-2Reference
Starter volts12Reference
Coolant capacity19.9 LReference
Intake valve clearance0.305 mmReference
Exhaust valve clearance0.305 mmReference
Oil capacity15.1 LReference
Transmission
9-speed unsynchronizedReference
TypeunsynchronizedReference
Gears9 forward and 2 reverseReference
Oil capacity39.7 LReference
Oil typeSAE 80-90 or 90 GL-5Reference
Tractor must be stopped and clutch used to change gears or ranges. With the shift lever in neutral and clutch pressed, a knob on top can be rotated to select range, then the lever can be moved to select the gear.Reference
PTO & Hydraulics
PTO (claimed)44.0 kWReference
Hydraulic system17.0 LReference
Typeopen centerReference
Capacity17.0 LReference
Pressure196.5 barReference
Valves2Reference
Pump flow34.1 lpmReference
Steering flow20.8 lpmReference
Steering press.103.4 barReference
Rear TypeIIReference
Rear lift (at ends)1508 kgReference
Rear PTOindependentReference
Rear PTO Type540/groundReference
Capacities
Fuel128.7 LReference
Dimensions
Wheelbase237 cmReference
Weight3619 kgReference
Front tire7.50-20Reference
Rear tire15.5-38Reference
Ag front7.50-20Reference
Ag rear15.5-38Reference
Length386 cmReference
Height (hood)164 cmReference
Height (ROPS)271 cmReference
Shipping weight3619 kgReference
Max weight5443 kgReference
Clearance (front axle)44 cmReference
Clearance (rear axle)54 cmReference
Clearance (drawbar)30 cmReference
Electrical
GroundnegativeReference
Charging systemalternatorReference
Charging amps50Reference
Batteries2Reference
Battery CCA900Reference
Battery volts6Reference
Speeds
15.8x38 rear tires.Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
