Tractor · 1994Unverified
Belarus 5170
Belarus 5170 · 74 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
74 hp
Weight
6834 to 8201 pounds
Hover a source tag to verify
Overview
ManufacturerBelarusReference
Two- or four-wheel driveReference
Differential lockhydraulic rear lockReference
Steeringhydrostatic powerReference
Mechanical dry disc brakesReference
Four-post ROPS. Cab optional.Reference
Engine
Belarus 4.8L 4-cyl dieselReference
Belarus D240Reference
dieselReference
4-cylinderReference
liquid-cooledReference
Displacement4.8 LReference
Bore/Stroke110 x 125 mmReference
Fuel systemdirect injectionReference
Air cleaneroil bath with pre-cleanerReference
Compression16:1Reference
Rated RPM2200Reference
Idle RPM600-2385Reference
StarterelectricReference
Starter volts24Reference
Oil capacity15.0 LReference
Coolant capacity19.0 LReference
Transmission
18-speedReference
Gears18 forward and 4 reverseReference
Clutchdry discReference
Oil capacity40.0 LReference
Nine gears in two ranges.Reference
PTO & Hydraulics
PTO (claimed)55.2 kWReference
Hydraulic system18.2 LReference
Typelive open centerReference
Capacity18.2 LReference
Pressure193.1 barReference
Valves2Reference
Pump flow37.5 lpmReference
Rear TypeIIReference
Rear lift1995 kgReference
Rear PTOindependentReference
Rear PTO Type540/1000 (1.375)Reference
Capacities
Fuel108.3 LReference
Dimensions
Wheelbase244 cmReference
Weight6834 to 8201 poundsReference
Front tire9.0x20Reference
Rear tire15.5x38 (2WD)Reference
Standard tires (ag)Front: 9.0x20. Rear: 15.5x38 (2WD)Reference
Standard tires (ag)Front: 11.2x20. Rear: 15.5x38 (4WD)Reference
Length392 cmReference
Width196 cmReference
Height (hood)163 cmReference
Height (cab)275 cmReference
Ground clearance46 cmReference
Front tread145 to 180 cmReference
Rear tread145 to 210 cmReference
2WD ROPS Shipping3099 kgReference
2WD Cab Shipping3470 kgReference
4WD ROPS Shipping3299 kgReference
4WD Cab Shipping3719 kgReference
Electrical
GroundnegativeReference
Charging systemalternatorReference
Charging amps50Reference
Batteries2Reference
Battery volts12Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
