Tractor · 1996Unverified

Belarus 5270

Name: Belarus 5270
Brand: Belarus

Belarus 5270 · 74 hp. Reference specifications; pending source verification.

The Belarus 5270 is a tractor with a rated output of 74 hp, positioning it roughly in the middle of its class in terms of power. It was manufactured in 1996 and features a 4-cylinder diesel liquid-cooled engine, coupled with a hydrostatic transmission that drives four-wheel drive. The tractor's weight is listed as 3664 kg, and it is designed for use on jobs covering approximately 200 acres.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

74 hp

Weight

3664 kg

Catalogue coverage

Variants represented

Richest spec table

57 rows

Recorded power

74 hp

Recorded weight

3664 kg

Transmissions

14-speed partially synchronized

Production years

1996-1996

Verified variants

No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.

Hover a source tag to verify

Overview

ManufacturerBelarusReference

Four-wheel driveReference

Differential lockhydraulic rear lockReference

Steeringhydrostatic powerReference

Mechanical dry disc brakesReference

Cab with heater.Reference

Engine

Belarus 4.8L 4-cyl dieselReference

Belarus D243Reference

dieselReference

4-cylinderReference

liquid-cooledReference

Displacement4.8 LReference

Bore/Stroke110 x 125 mmReference

Fuel systemdirect injectionReference

Air cleaneroil bath with pre-cleanerReference

Compression16:1Reference

Rated RPM2200Reference

Idle RPM600-2385Reference

StarterelectricReference

Starter volts24Reference

Oil capacity15.0 LReference

Coolant capacity19.0 LReference

Transmission

14-speed partially synchronizedReference

Typepartially synchronizedReference

Gears14 forward and 4 reverseReference

Clutchdry discReference

Oil capacity40.0 LReference

PTO & Hydraulics

PTO (claimed)55.2 kWReference

Hydraulic system18.2 LReference

Typelive open centerReference

Capacity18.2 LReference

Pressure193.1 barReference

Valves3Reference

Pump flow37.5 lpmReference

Rear TypeIIReference

Rear lift1599 kgReference

Rear PTOindependentReference

Rear PTO Type540/1000 (1.375)Reference

Capacities

Fuel108.3 LReference

Dimensions

Wheelbase245 cmReference

Weight3664 kgReference

Front tire13.6x20Reference

Rear tire18.4x34Reference

Standard tires (ag)Front: 13.6x20. Rear: 18.4x34Reference

Length389 cmReference

Width197 cmReference

Height (hood)168 cmReference

Height (cab)278 cmReference

Shipping weight3664 kgReference

Ground clearance46 cmReference

Front tread145 to 180 cmReference

Rear tread145 to 210 cmReference

Electrical

GroundnegativeReference

Charging systemalternatorReference

Charging amps50Reference

Batteries2Reference

Battery volts12Reference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
