Tractor · 1996Unverified
Belarus 5290
Belarus 5290 · 93 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
93 hp
Weight
3685 kg
Hover a source tag to verify
Overview
ManufacturerBelarusReference
Four-wheel driveReference
Differential lockhydraulic rear lockReference
Steeringhydrostatic powerReference
Mechanical dry disc brakesReference
Cab with heater.Reference
Engine
Belarus 4.8L 4-cyl dieselReference
Belarus D243Reference
turbocharged dieselReference
4-cylinderReference
liquid-cooledReference
Displacement4.8 LReference
Bore/Stroke110 x 125 mmReference
Fuel systemdirect injectionReference
Air cleaneroil bath with pre-cleanerReference
Compression16:1Reference
Rated RPM1800Reference
Idle RPM600-1950Reference
StarterelectricReference
Starter volts24Reference
Oil capacity15.0 LReference
Coolant capacity19.0 LReference
Transmission
14-speed partially synchronizedReference
Typepartially synchronizedReference
Gears14 forward and 4 reverseReference
Clutchdry discReference
Oil capacity40.0 LReference
PTO & Hydraulics
PTO (claimed)69.4 kWReference
Hydraulic system18.2 LReference
Typelive open centerReference
Capacity18.2 LReference
Pressure193.1 barReference
Valves3Reference
Pump flow37.5 lpmReference
Rear TypeIIReference
Rear lift1599 kgReference
Rear PTOindependentReference
Rear PTO Type540/1000 (1.375)Reference
Capacities
Fuel108.3 LReference
Dimensions
Wheelbase245 cmReference
Weight3685 kgReference
Front tire13.6x20Reference
Rear tire18.4x34Reference
Standard tires (ag)Front: 13.6x20. Rear: 18.4x34Reference
Length392 cmReference
Width197 cmReference
Height (hood)168 cmReference
Height (cab)278 cmReference
Shipping weight3685 kgReference
Ground clearance46 cmReference
Front tread145 to 180 cmReference
Rear tread145 to 210 cmReference
Electrical
GroundnegativeReference
Charging systemalternatorReference
Charging amps50Reference
Batteries2Reference
Battery volts12Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
