Tractor · 1997Unverified
Belarus 5380
Belarus 5380 · 85 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
85 hp
Weight
3685 kg
Hover a source tag to verify
Overview
ManufacturerBelarusReference
Four-wheel driveReference
Differential lockhydraulic rear lockReference
Steeringhydrostatic powerReference
Mechanical dry disc brakesReference
Cab with heater.Reference
Variants
538014-speedReference
5380S9-speed shuttleReference
Engine
Belarus 4.8L 4-cyl dieselReference
Belarus D243TReference
turbocharged dieselReference
4-cylinderReference
liquid-cooledReference
Displacement4.8 LReference
Bore/Stroke110 x 125 mmReference
Fuel systemdirect injectionReference
Compression16:1Reference
Rated RPM2200Reference
Idle RPM600-2350Reference
StarterelectricReference
Starter volts24Reference
Oil capacity10.8 LReference
Coolant capacity19.0 LReference
Transmission
14-speed partially synchronizedReference
9-speed shuttleReference
Typepartially synchronizedReference
Gears14 forward and 4 reverseReference
Clutchdry discReference
Oil capacity33.3 LReference
TypeshuttleReference
Gears9 forward and reverseReference
PTO & Hydraulics
PTO (claimed)63.4 kWReference
Hydraulic system18.2 LReference
Typelive open centerReference
Capacity18.2 LReference
Valves3Reference
Rear TypeIIReference
Rear lift1995 kgReference
Rear PTOindependentReference
Rear PTO Type540/1000 (1.375)Reference
Capacities
Fuel108.3 LReference
Dimensions
Wheelbase245 cmReference
Weight3685 kgReference
Front tire13.6x20Reference
Rear tire18.4x34Reference
Standard tires (ag)Front: 13.6x20. Rear: 18.4x34Reference
Length394 cmReference
Width197 cmReference
Height (hood)166 cmReference
Height (cab)276 cmReference
Shipping weight3685 kgReference
Ground clearance46 cmReference
Front tread145 to 180 cmReference
Rear tread145 to 210 cmReference
Electrical
GroundnegativeReference
Charging systemalternatorReference
Charging amps50Reference
Batteries2Reference
Battery volts12Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
