The Belarus 5470 is a tractor rated at 74 hp — putting it around the middle of its class for power. Power comes from a 4-cylinder diesel liquid-cooled engine, driving through four-wheel drive with a hydrostatic transmission. It is aimed at jobs of around up to 200 ac. Recorded specifications in UK and US units are listed below.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
74 hp
Catalogue coverage
Variants represented
2
Richest spec table
32 rows
Recorded power
74 hp
Transmissions
14-speed partially synchronized
Verified variants
0
No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.
Hover a source tag to verify
Overview
ManufacturerBelarusReference
Four-wheel driveReference
Steeringhydrostatic powerReference
Cab with heater.Reference
Variants
547014-speedReference
5470S9-speed shuttleReference
Engine
Belarus 4.8L 4-cyl dieselReference
Belarus D243Reference
dieselReference
4-cylinderReference
liquid-cooledReference
Displacement4.8 LReference
Bore/Stroke110 x 125 mmReference
Fuel systemdirect injectionReference
StarterelectricReference
Starter volts24Reference
Transmission
14-speed partially synchronizedReference
9-speed shuttleReference
Typepartially synchronizedReference
Gears14 forward and 4 reverseReference
TypeshuttleReference
Gears9 forward and 8 reverseReference
PTO & Hydraulics
PTO (claimed)55.2 kWReference
Typeopen centerReference
Rear TypeIIReference
Rear PTOindependentReference
Rear PTO Type540/1000 (1.375)Reference
Electrical
GroundnegativeReference
Charging systemalternatorReference
Charging amps50Reference
Batteries2Reference
Battery volts12Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
