Tractor · Unverified
Belarus 5490
Belarus 5490 — ???? - 2009 5400 Series · 93 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
93 hp
Hover a source tag to verify
Overview
ManufacturerBelarusReference
Four-wheel driveReference
Steeringhydrostatic powerReference
Cab with heater and air-conditioning.Reference
Variants
549014-speedReference
5490S9-speed shuttleReference
Engine
Belarus 4.8L 4-cyl dieselReference
Belarus D245.5Reference
turbocharged dieselReference
4-cylinderReference
liquid-cooledReference
Displacement4.8 LReference
Bore/Stroke110 x 125 mmReference
Fuel systemdirect injectionReference
Rated RPM1800Reference
StarterelectricReference
Starter volts24Reference
Transmission
14-speed partially synchronizedReference
9-speed shuttleReference
Typepartially synchronizedReference
Gears14 forward and 4 reverseReference
TypeshuttleReference
Gears9 forward and 8 reverseReference
PTO & Hydraulics
PTO (claimed)69.4 kWReference
Typeopen centerReference
Rear TypeIIReference
Controlposition and draft controlReference
Rear PTOindependentReference
Rear PTO Type540/1000 (1.375)Reference
Dimensions
Front tire13.6x20Reference
Rear tire18.4x34Reference
Standard tires (ag)Front: 13.6x20. Rear: 18.4x34Reference
Electrical
GroundnegativeReference
Charging systemalternatorReference
Charging amps50Reference
Batteries2Reference
Battery volts12Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
