Tractor · 2011Unverified
Belarus 5560
Belarus 5560 — Utility tractor · 65 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
65 hp
Weight
4100 kg
Hover a source tag to verify
Overview
ManufacturerBelarusReference
Utility tractorReference
Four-wheel driveReference
Differential lockhydraulic rearReference
Steeringhydrostatic powerReference
Mechanical dry disc brakesReference
Cab with heater.Reference
Engine
4.8L 4-cyl dieselReference
Fuel tank108.3 LReference
D243Reference
dieselReference
4-cylinderReference
liquid-cooledReference
Displacement4.8 LReference
Bore/Stroke108 x 121 mmReference
Fuel systemdirect injectionReference
Rated RPM2200Reference
Transmission
14-speed partially synchronizedReference
Typepartially synchronizedReference
Gears14 forward and 4 reverseReference
Clutchdry discReference
PTO & Hydraulics
PTO (claimed)48.5 kWReference
Rear TypeIIReference
Controldraft and position controlReference
Rear lift (at ends)3196 kgReference
Rear PTOindependentReference
Rear PTO Type540/1000Reference
Dimensions
Wheelbase245 cmReference
Weight4100 kgReference
Front tire11.2x20Reference
Rear tire15.5x38Reference
Standard tires (ag)Front: 11.2x20. Rear: 15.5x38Reference
Length394 cmReference
Width196 cmReference
Height (hood)162 cmReference
Height (cab)274 cmReference
Ground clearance46 cmReference
Front tread144 to 184 cmReference
Rear tread144 to 209 cmReference
Speeds
With 15.5x38 rear tires.Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
