Tractor · 2011Unverified
Belarus 5570
Belarus 5570 — Utility tractor · 87 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
87 hp
Weight
4296 kg
Hover a source tag to verify
Overview
ManufacturerBelarusReference
Utility tractorReference
Four-wheel driveReference
Differential lockhydraulic rearReference
Steeringhydrostatic powerReference
Mechanical wet disc brakesReference
Cab with heater.Reference
Engine
4.8L 4-cyl dieselReference
Fuel tank108.3 LReference
Engine64.9 kWReference
D243Reference
dieselReference
4-cylinderReference
liquid-cooledReference
Displacement4.8 LReference
Bore/Stroke108 x 121 mmReference
Power64.9 kWReference
Rated RPM2200Reference
Transmission
14-speed partially synchronizedReference
Typepartially synchronizedReference
Gears14 forward and 4 reverseReference
Clutchdry discReference
PTO & Hydraulics
Rear TypeIIReference
Controldraft and position controlReference
Rear lift (at ends)3196 kgReference
Rear PTOindependentReference
Rear PTO Type540/1000Reference
Dimensions
Wheelbase245 cmReference
Weight4296 kgReference
Front tire360/70R24Reference
Rear tire18.4x34Reference
Standard tires (ag)Front: 360/70R24. Rear: 18.4x34Reference
Length394 cmReference
Width196 cmReference
Height (hood)166 cmReference
Height (cab)276 cmReference
Front tread142 to 196 cmReference
Rear tread149 to 210 cmReference
Speeds
With 18.4-34 rear tires.Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
