Tractor · 1981Unverified
Belarus 560
Belarus 560 · 58 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
58 hp
Weight
3039 kg
Hover a source tag to verify
Overview
ManufacturerBelarusReference
Built in Minsk, BelarusReference
Original price was $12,000 in 1992Reference
Two-wheel driveReference
Power steeringReference
Disc brakesReference
Variants
5602WDReference
5624WDReference
Engine
Belarus 4.8L 4-cyl dieselReference
Engine52.2 kWReference
Belarus D50Reference
dieselReference
4-cylinderReference
liquid-cooledReference
Displacement4.8 LReference
Bore/Stroke110 x 125 mmReference
Power52.2 kWReference
Compression16:1Reference
Rated RPM1800Reference
Coolant capacity20.0 LReference
Transmission
9-speed sliding gearReference
Typesliding gearReference
Gears9 forward and 2 reverseReference
Clutch325mm dry discReference
Oil capacity39.9 LReference
PTO & Hydraulics
PTO (claimed)43.3 kWReference
Hydraulic system20.4 LReference
Typeopen centerReference
Capacity20.4 LReference
Pressure134.5 barReference
Valves3Reference
Pump flow39.7 lpmReference
Rear TypeIIReference
Controlposition and draft controlReference
Rear lift (at ends)1678 kgReference
Rear PTOindependentReference
Rear PTO Type540 (1.375)Reference
Engine RPM540@1630Reference
Engine RPM596@1800Reference
Capacities
Fuel129.8 LReference
Dimensions
Wheelbase237 cmReference
Weight3039 kgReference
Front tire7.50x20Reference
Rear tire15.5x38Reference
Standard tires (ag)Front: 7.50x20. Rear: 15.5x38Reference
Shipping weight3039 kgReference
Front tread119 to 180 cmReference
Rear tread119 to 180 cmReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
