Tractor · 2011Unverified
Belarus 6520
Belarus 6520 — Row-Crop tractor · 125 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
125 hp
Weight
5090 kg
Hover a source tag to verify
Overview
ManufacturerBelarusReference
Row-Crop tractorReference
Four-wheel driveReference
Differential lockelectro-hydraulicReference
Steeringhydrostatic powerReference
Disc brakesReference
Cab with heater.Reference
Engine
7.1L 6-cyl dieselReference
Fuel tank108.3 LReference
D260.2Reference
turbocharged dieselReference
6-cylinderReference
liquid-cooledReference
Displacement7.1 LReference
Rated RPM2100Reference
Transmission
16-speed partially synchronizedReference
Typepartially synchronizedReference
Gears16 forward and 8 reverseReference
Clutchdry discReference
PTO & Hydraulics
PTO (claimed)93.2 kWReference
Typeopen centerReference
Rear TypeIIIReference
Controldraft and position controlReference
Rear PTOindependentReference
Rear PTO Type540/1000Reference
Dimensions
Wheelbase274 cmReference
Weight5090 kgReference
Front tire14.9Rx24Reference
Rear tire18.4Rx38Reference
Standard tires (ag)Front: 14.9Rx24. Rear: 18.4Rx38Reference
Length494 cmReference
Width196 cmReference
Height (cab)289 cmReference
Front tread149 to 179 cmReference
Rear tread149 to 210 cmReference
Speeds
With 18.4x38 rear tires.Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
