Tractor · 1976Unverified
Belarus 7010
Belarus 7010 — Four-wheel Drive (4WD) tractor · 215 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
215 hp
Weight
13487 kg
Hover a source tag to verify
Overview
DistributorBelarusReference
ManufacturerKirovetsReference
Four-wheel Drive (4WD) tractorReference
Built in Saint Petersburg, RussiaReference
Four-wheel driveReference
Articulated power steeringReference
Pneumatic shoe brakesReference
Cab standard with heater. Optional air-conditioning.Reference
Engine
YaMZ 14.9L 8-cyl dieselReference
Engine175.2 kWReference
YaMZReference
turbocharged dieselReference
8-cylinderReference
liquid-cooledReference
Displacement14.9 LReference
Bore/Stroke130 x 140 mmReference
Power175.2 kWReference
Air cleanerdryReference
Compression16.5:1Reference
Rated RPM1700Reference
StarterelectricReference
Starter volts24Reference
Oil capacity29.3 LReference
Coolant capacity65.3 LReference
Transmission
16-speed partially synchronizedReference
Typepartially synchronizedReference
Gears16 forward and 8 reverseReference
Clutchhydraulic discReference
Oil capacity22.7 LReference
Four gears (1-4) in four ranges (I-IV) plus two reverse ranges. Gear shifts within a range are synchronized.Reference
PTO & Hydraulics
PTO (claimed)160.3 kWReference
Hydraulic system124.9 LReference
Capacity124.9 LReference
Valves2Reference
Pump flow67.4 lpmReference
Steering flow160.1 lpmReference
Rear TypeIIIReference
Rear PTOindependentReference
Rear PTO Type1000 (2.125)Reference
Capacities
Fuel643.5 LReference
Dimensions
Wheelbase320 cmReference
Weight13487 kgReference
Front tire28.1-26Reference
Rear tire28.1-26Reference
Ag front28.1-26Reference
Ag rear28.1-26Reference
Length739 cmReference
Height (cab)353 cmReference
Ground clearance43 cmReference
Front tread210 cmReference
Rear tread210 cmReference
Electrical
Charging systemalternatorReference
Charging amps80Reference
Battery volts12Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
