Tractor · 1978Unverified
Belarus 7100
Belarus 7100 — Four-wheel Drive (4WD) tractor · 270 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
270 hp
Max power
186.2 kW
Weight
13487 kg
Hover a source tag to verify
Overview
ManufacturerBelarusReference
Four-wheel Drive (4WD) tractorReference
Built in Minsk, BelarusReference
Four-wheel driveReference
Articulated power steeringReference
Pneumatic drum brakesReference
Cab standard with heat.Reference
Variants
K-701similar Kirovets modelReference
Engine
Belarus 22.3L 12-cyl dieselReference
Engine223.7 kWReference
Drawbar (tested)186.2 kWReference
BelarusReference
turbocharged dieselReference
12-cylinderReference
liquid-cooledReference
Displacement22.3 LReference
Bore/Stroke130 x 140 mmReference
Power223.7 kWReference
Air cleanerdryReference
Compression16.5:1Reference
Rated RPM1900Reference
StarterelectricReference
Starter volts24Reference
Coolant capacity94.6 LReference
Power at rated engine speed201.1 kWReference
Max power186.2 kWReference
Transmission
16-speed four-speed power shiftReference
Typefour-speed power shiftReference
Gears16 forward and 8 reverseReference
Clutchhydraulic discReference
Four power shift gears in four ranges.Reference
PTO & Hydraulics
PTO (claimed)193.9 kWReference
PTO (tested)201.1 kWReference
Hydraulic system124.9 LReference
Typeopen centerReference
Capacity124.9 LReference
Valves3Reference
Pump flow126.4 lpmReference
Steering flow175.2 lpmReference
Rear TypeIIIReference
Rear PTOindependentReference
Rear PTO Type1000 (1.75)Reference
Capacities
Fuel643.5 LReference
Dimensions
Wheelbase320 cmReference
Weight13487 kgReference
Front tire28.1-26Reference
Rear tire28.1-26Reference
Ag front28.1-26Reference
Ag rear28.1-26Reference
Length739 cmReference
Height (cab)353 cmReference
Shipping weight13487 kgReference
Ground clearance43 cmReference
Electrical
Charging systemalternatorReference
Charging amps80Reference
Test results
Diesel 16-speed 4WDNovember 17 - 30, 1979Link: Nebraska Tractor Test 1334 fileReference
PTO performanceReference
Fuel use64.3 l/hourReference
Drawbar performanceReference
Fuel use63.6 l/hourReference
Max pull13991 kgReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
