Tractor · 1977Unverified
Belarus 820
Belarus 820 · 75 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
75 hp
Weight
3243 kg
Hover a source tag to verify
Overview
ManufacturerBelarusReference
Built in Minsk, BelarusReference
Original price was $21,000 in 1996Reference
Four-wheel driveReference
Final drivesspur gearReference
Differential lockmechanical rearReference
Power steeringReference
Disc brakesReference
Variants
8002WDReference
8204WDReference
Engine
Belarus 4.7L 4-cyl dieselReference
Engine63.4 kWReference
BelarusReference
dieselReference
4-cylinderReference
liquid-cooledReference
Displacement4.7 LReference
Bore/Stroke110 x 125 mmReference
Power63.4 kWReference
Air cleaneroil bathReference
Rated RPM2200Reference
Torque267.1 NmReference
Torque RPM1000Reference
Oil capacity15.0 LReference
Coolant capacity20.0 LReference
Transmission
18-speed gearReference
TypegearReference
Gears18 forward and 4 reverseReference
Clutch325mm dry discReference
Oil capacity39.9 LReference
PTO & Hydraulics
PTO (claimed)55.8 kWReference
Hydraulic system20.4 LReference
Typeopen centerReference
Capacity20.4 LReference
Pressure156.8 barReference
Valves2Reference
Pump flow44.7 lpmReference
Rear TypeIIReference
Controlposition and draft controlReference
Rear lift (at ends)1995 kgReference
Rear PTOindependentReference
Rear PTO Type540/1000 (1.375)Reference
Engine RPM540@2068Reference
Engine RPM1000@2158Reference
Capacities
Fuel129.8 LReference
Dimensions
Wheelbase245 cmReference
Weight3243 kgReference
Front tire11.2x20Reference
Rear tire15.5-38Reference
Standard tires (ag)Front: 11.2x20. Rear: 15.5-38Reference
820 Serial Number Location
Serial number plate on the rear of the Belarus 820.Reference
Electrical
Charging systemalternatorReference
Battery volts12Reference
Speeds
With 15.5-38 rear tires.Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
