Tractor · 1996Unverified
Belarus 8345
Belarus 8345 — Row-Crop tractor · 75 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
75 hp
Max power
50.9 kW
Weight
3919 kg
Hover a source tag to verify
Overview
ManufacturerBelarusReference
Row-Crop tractorReference
Built in Minsk, BelarusReference
Original price$26,000 (1999)Reference
Four-wheel driveReference
Steeringhydrostatic powerReference
Differential dry disc brakesReference
Cab standard.Reference
Variants
80112WD ROPSReference
80454WD ROPSReference
83112WD cabReference
83454WD cabReference
Engine
Belarus 4.7L 4-cyl dieselReference
Engine60.4 kWReference
Drawbar (tested)50.9 kWReference
Belarus D243CReference
dieselReference
4-cylinderReference
liquid-cooledReference
Displacement4.7 LReference
Bore/Stroke110 x 125 mmReference
Power60.4 kWReference
Fuel systemdirect injectionReference
Air cleaneroil bathReference
Compression16:1Reference
Rated RPM2200Reference
Starter volts24Reference
Oil capacity15.1 LReference
Coolant capacity18.9 LReference
Power at rated engine speed56.2 kWReference
Max power50.9 kWReference
Transmission
14-speed partially synchronizedReference
9-speedReference
Typepartially synchronizedReference
Gears14 forward and 4 reverseReference
Oil capacity39.7 LReference
Seven gears (1-7) in two ranges (low/high). Synchronized shifting in gears three to seven.Reference
Gears9 forward and 8 reverseReference
PTO & Hydraulics
PTO (claimed)55.9 kWReference
PTO (tested)56.2 kWReference
Hydraulic system21.8 LReference
TypeopenReference
Capacity21.8 LReference
Pressure186.2 barReference
Valves2Reference
Pump flow45.4 lpmReference
Rear TypeIIReference
Rear lift (at ends)1980 kgReference
Rear PTOindependentReference
Rear PTO Type540/1000Reference
Engine RPM540@2106Reference
Engine RPM1000@2310Reference
Capacities
Fuel128.7 LReference
Dimensions
Wheelbase243 cmReference
Weight3919 kgReference
Front tire14.2-20Reference
Rear tire16.9-38Reference
Ag front14.2-20Reference
Ag rear16.9-38Reference
Operating weight3919 kgReference
Front tread152 to 180 cmReference
Rear tread152 to 210 cmReference
Test results
Diesel 14-speed 4WDOctober 23 - November 7, 1997Link: OCED Tractor Test 1742 fileReference
PTO performanceReference
Fuel use18.9 l/hourReference
Drawbar performanceReference
Gear 4H used for power test.Reference
Max pull3864 kgReference
Gear 2L used for pull test.Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
