Tractor · 1998Unverified
Belarus 9021
Belarus 9021 — Row-Crop tractor · 75 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
75 hp
Weight
3515 kg
Hover a source tag to verify
Overview
ManufacturerBelarusReference
Row-Crop tractorReference
Built in Minsk, BelarusReference
Original price21000 (1999)Reference
Two-wheel driveReference
Steeringhydrostatic powerReference
Dry disc brakesReference
ROPS.Reference
Variants
90112WD ROPSReference
90454WD ROPSReference
93112WD cabReference
93454WD cabReference
Engine
Belarus 4.7L 4-cyl dieselReference
Engine73.1 kWReference
Belarus D245.5Reference
turbocharged dieselReference
4-cylinderReference
liquid-cooledReference
Displacement4.7 LReference
Bore/Stroke110 x 125 mmReference
Power73.1 kWReference
Air cleaneroil bathReference
Compression16:1Reference
Rated RPM1800Reference
Starter volts24Reference
Oil capacity15.1 LReference
Coolant capacity18.9 LReference
Transmission
14-speed partially synchronizedReference
Typepartially synchronizedReference
Gears14 forward and 4 reverseReference
Clutchdry discReference
Oil capacity39.7 LReference
Seven gears (1-7) in two ranges (low/high). Synchronized shifting in gears three to seven. Lower gear, range, and shuttle shifting is not synchronized.Reference
PTO & Hydraulics
PTO (claimed)55.9 kWReference
Hydraulic system21.8 LReference
TypeopenReference
Capacity21.8 LReference
Valves2Reference
Pump flow45.4 lpmReference
Rear TypeIIReference
Rear lift (at ends)1980 kgReference
Rear PTOindependentReference
Rear PTO Type540/1000Reference
Engine RPM540@1632Reference
Engine RPM1000@1673Reference
Capacities
Fuel128.7 LReference
Dimensions
Wheelbase238 cmReference
Weight3515 kgReference
Front tire6.5-16Reference
Rear tire14.9-30Reference
Ag front6.5-16Reference
Ag rear14.9-30Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
