Tractor · 1961Unverified
Belarus T-40
Belarus T-40 — Row-Crop tractor · 37 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
37 hp
Weight
5223 to 5730 pounds
Hover a source tag to verify
Overview
ManufacturerBelarusReference
Row-Crop tractorReference
Built in Lipetsk, RussiaReference
Two- or four-wheel driveReference
Manual steeringReference
Cab standard.Reference
Variants
T-402WDReference
T-40A4WDReference
Engine
Vladimir 4.1L 4-cyl dieselReference
Engine27.6 kWReference
Vladimir D-37Reference
dieselReference
4-cylinderReference
air-cooledReference
Displacement4.1 LReference
Bore/Stroke105 x 120 mmReference
Power27.6 kWReference
Rated RPM1600Reference
Idle RPM800-1750Reference
Starterpony motorReference
StarterelectricReference
Starter volts12Reference
Oil capacity11.0 LReference
Transmission
7-speed gearReference
12-speed creeperReference
TypegearReference
Gears7 forward and 1 reverseReference
Seven forward gears plus reverse. Russian literature refers to the lowest gear as "slow" and the next gear as "first".Reference
TypecreeperReference
Gears12 forward and 2 reverseReference
Additional creeper range to the standard transmission. The two highest gears should not be used in creeper range.Reference
Capacities
Fuel74.2 LReference
Aux. fuel3.0 LReference
PTO & Hydraulics
Hydraulic system14.4 LReference
Capacity14.4 LReference
Rear PTO Type540/groundReference
Dimensions
2WD Wheelbase214 cmReference
4WD Wheelbase225 cmReference
Weight5223 to 5730 poundsReference
Front tire6.50-16Reference
2WD Rear tire12.4/11-38Reference
2WD Standard tires (ag)Front: 6.50-16. Rear: 12.4/11-38Reference
4WD Standard tires (ag)Front: 8.3/8-20. Rear: 12.4/11-38Reference
2WD Length366 cmReference
4WD Length384 cmReference
Width162 cmReference
Height (cab)236 cmReference
2WD Weight2369 kgReference
4WD Weight2599 kgReference
Clearance (front axle)54 cmReference
Clearance (rear axle)50 cmReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
