Tractor · 1987Unverified

Big Bud 740

Name: Big Bud 740
Brand: Big Bud

Big Bud 740 — 4 Series · 740 hp. Reference specifications; pending source verification.

The Big Bud 740 is a tractor with a rating of around 740 hp, positioning it at the higher end of its class in terms of power. It was produced between 1987 and 1990. The tractor features a 6-cylinder turbocharged intercooled diesel liquid-cooled engine, coupled with four-wheel drive and a hydrostatic transmission. It has an operating weight of 34,020 kg and is suited for operations on 1,500+ acres.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

740 hp

Weight

34020 kg

Catalogue coverage

Variants represented

Richest spec table

23 rows

Recorded power

740 hp

Recorded weight

34020 kg

Transmissions

12-speed full power shift

Production years

1987-1990

Verified variants

No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.

Hover a source tag to verify

Overview

ManufacturerBig BudReference

Four-wheel Drive (4WD) tractorReference

Built in Havre, Montana, USAReference

Total built2Reference

Drive4x4 4WDReference

Steeringhydrostatic powerReference

Cab standard.Reference

Engine

Komatsu 23.2L 6-cyl dieselReference

Engine551.8 kWReference

Komatsu SA6 D170Reference

turbocharged intercooled dieselReference

6-cylinderReference

liquid-cooledReference

Displacement23.2 LReference

Bore/Stroke170 x 170 mmReference

Power551.8 kWReference

Starter typeelectricReference

Transmission

12-speed full power shiftReference

TransmissionTwin DiscReference

Typefull power shiftReference

Gears12 forward and 2 reverseReference

Dimensions

Weight34020 kgReference

Electrical

GroundnegativeReference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
