Tractor · 1976Unverified
Big Bud HN320
Big Bud HN320 — HN Series · 320 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
320 hp
Weight
16329 kg
Hover a source tag to verify
Overview
ManufacturerBig BudReference
Four-wheel Drive (4WD) tractorReference
Built in Havre, Montana, USAReference
Four-wheel driveReference
Steeringhydrostatic powerReference
Cab standard.Reference
Engine
Cummins 14.0L 6-cyl dieselReference
Fuel tank1987.1 LReference
Engine238.6 kWReference
Cummins NT855Reference
turbocharged intercooled dieselReference
6-cylinderReference
liquid-cooled inlineReference
Displacement14.0 LReference
Bore/Stroke140 x 152 mmReference
Power238.6 kWReference
Rated RPM2100Reference
Starter typeelectricReference
Transmission
12-speed gearReference
TransmissionFullerReference
TypegearReference
Gears12 forward and 2 reverseReference
PTO & Hydraulics
Typeopen centerReference
Pump flow75.7 lpmReference
Total flow151.4 lpmReference
Steering flow75.7 lpmReference
Dimensions
Weight16329 kgReference
Front tire23.1x30Reference
Rear tire23.1x30Reference
Ag front23.1x30Reference
Ag rear23.1x30Reference
Shipping weight16329 kgReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
