Tractor · 1977Unverified
Big Bud HN360
Big Bud HN360 — HN Series · 360 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
360 hp
Weight
17690 kg
Hover a source tag to verify
Overview
ManufacturerBig BudReference
Four-wheel Drive (4WD) tractorReference
Built in Havre, Montana, USAReference
Four-wheel driveReference
Steeringhydrostatic powerReference
Cab standard.Reference
Engine
Cummins 14.0L 6-cyl dieselReference
Engine268.5 kWReference
Cummins NTA855Reference
turbocharged aftercooled dieselReference
6-cylinderReference
liquid-cooledReference
Displacement14.0 LReference
Bore/Stroke140 x 152 mmReference
Power268.5 kWReference
Rated RPM2100Reference
Starter typeelectricReference
Transmission
12-speed gearReference
TransmissionFullerReference
TypegearReference
Gears12 forward and 2 reverseReference
Dimensions
Weight17690 kgReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
