Lawn Tractor · 2020Unverified
Bobcat 9994001
Bobcat 9994001 — ZS4000 Series · 19 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
19 hp
Weight
362 kg
Hover a source tag to verify
Overview
ManufacturerBobcatReference
Zero-turn mowerReference
Built in Johnson Creek, Wisconsin, USAReference
Two-wheel driveReference
Power steeringReference
Stand-on open station.Reference
Engine
19HP Kawasaki 603cc 2-cyl gasolineReference
Fuel tank19.3 LReference
Kawasaki FX600VReference
gasolineReference
2-cylinderReference
air-cooled vertical-shaft V-TwinReference
Displacement36.8 ciReference
Bore/Stroke73 x 72 mmReference
Power14.2 kWReference
Air cleanerdryReference
StarterelectricReference
Starter volts12Reference
Transmission
hydrostaticReference
TransmissionHydro-Gear ZT-3100Reference
TypehydrostaticReference
Gearsinfinite forward and reverseReference
Dimensions
Weight362 kgReference
Front tire11x6.0-5Reference
Rear tire20x8.0-10Reference
Lawn/turf front11x6.0-5Reference
Lawn/turf rear20x8.0-10Reference
Length162 cmReference
Bobcat 9994001 attachments
36" mid-mount mower deckReference
Electrical
GroundnegativeReference
Charging amps15Reference
Battery volts12Reference
36" Mower deck
Typemid-mount BobcatReference
Type3-bladeReference
Cutting width91 cmReference
Cut height3 to 11 cmReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
